Control start/stop
Footswitches provide convenient, hands-free operation of the pump drives. Longer Pump provides different footswitches with different interfaces for different pump.
Footswitch has two kinds of working modes.Trigger: Press footswitch, the pump starts running; Press footswitch again, the pump stops. Gated: The pump runs as long as the footswitch is pressed.
Technical Specifications
Model | Product Code | Applicable pump model |
JK-2 | 05.49.37B | FK-1C distribution controller |
JK-3 | 05.49.37C | Peristaltic pumps of BT series and WT series with DB15 port |
JK-4 | 05.49.37D | For LSP series lab syringe pumps, Trigger mode |
JK-5 | 05.49.37E | For TJ series lab syringe pumps |
JK-6 | 05.49.37F | For TS series lab syringe pumps |
JK-8 | 05.49.37G | YT600-1J |
JK-9 | 05.49.37H | For G300-3F, WT600-3J, WT600-4F, (not for WT600-3J-E/K and WT600-4F-E/K) |
JK-15 | 05.49.37J | For G series Industrial Peristaltic Pump |
JK-14 | 05.49.37N | LPP01-100,need 2 pcs |
JK-4-1 | 05.49.37R | For LSP series lab syringe pumps,Gated mode |
