Speed resolution

0.1rpm

* Direction control

Direction is controlled by external switch signal.CW when switch is open, CCW when switch is closed

* Start/stop control

Start/stop is controlled by external switch signal. Pump runs when switch is open, stops when switch is closed

* BCD dial switch speed control

The speed is divided into 15 grades. BCD position 1-F corresponding to (rpm)5,10,15,20,25,30,35,40,45,50,60,70,80,90,100 (rpm)

* External speed control (optional)

4-20mA corresponding to 0.1-100rpm, 0-5V corresponding to 0-100rpm、0-10V corresponding to 0-100rpm, 0-10kHz corresponding to 0-100rpm

** Communication pump ID

Pump ID range is 1-30

** Bit rate

1200bps or 9600bps

Dimension (L×W×H)

118×60×81 (mm)

Relative humidity

＜80%

Operating temperature

0℃-40℃

Power supply

DC11.4V-25.2V

Power consumption

≤12W

Weight

0.54kg

T100-S300&JY15-12-A

056030A

Dial switch and external signal (4-20mA)

CE certified and Meet RoHS requirement

T100-S301&JY15-12-A

056031A

Dial switch and external signal (0-5V)

T100-S302&JY15-12-A

056032A

Dial switch and external signal (0-10V)

T100-S303&JY15-12-A

056033A

Dial switch and external signal (0-10kHz)

T100-S500&JY15-12-A

056034A

RS485 communication
